NEXCOM, a leading global supplier of network appliances, consolidates compute, security, and network functions into a single, AI-ready desktop – DNA 140. With zero-touch recovery, multi-network connectivity, and real-time network intelligence, DNA 140 fuses advanced Next-Generation Firewall (NGFW), intelligent SD-WAN routing, dual 5G failover, and AI hardware acceleration into a compact, deploy-anywhere appliance.

Built for the Edge

Powered by the Intel Atom^® x7000RE/E/C series, DNA 140 delivers low-latency, high-efficiency compute for real-time, edge-critical workloads. Four 2.5GbE LAN ports enable high-throughput local networking, while two PoE+ ports (30W, 802.3at) simplifies peripheral deployment for powered devices, TPM 2.0 ensures secure, hardware-level key protection.

Dual 5G for Redundant, Multi Connectivity

Equipped with dual 5G failover, DNA 140 ensures always-on uptime. One 5G line handles public access, the other connects privately—ideal for hybrid networks or failover setups. No dropouts. No dead zones. Just seamless access and control.

Network Protection and Embedded Security

DNA 140 is purpose-built for NGFW performance, enabling DPI, IPS, and real-time threat detection. Integrated with SD-WAN firewall, it ensures intelligent path selection and unified policy enforcement—delivering secure, high-performance connectivity across sites.

System Integrity with NEXBOOT Self-Recovery

DNA 140 features NEXBOOT, a built-in system-level failover and diagnostic suite minimizing downtime by autonomously restoring system functions after software faults or failed updates.

In a world where downtime is not an option, the DNA 140 keeps operations running at full power. Optimized for NGFW, SD-WAN firewall, with dual 5G failover and AI acceleration, this compact workhorse is built for the edge—remote branches, retail floors, or anywhere that can’t afford to go dark.

DNA 140 is the next-gen edge platform your IT infrastructure has been waiting for. Want to know why? Check out the full blog here.

Main Features

• Intel Atom^® x7000RE/E/C processor
• 1 x SO-DIMM slot for DDR5, 4800 MT/s , ECC/non-ECC, up to 16 GB
• eMMC 32GB onboard
• 4 x 2.5GbE RJ45 ports
  - 2 x PoE+ ports, supports up to 30W (802.3at) (optional)
• 1 x 1GbE management port
• 2 x M.2 3042/3052 for LTE/5G FR1 modules
• 1 x mini-PCIe for AI card or Wi-Fi module
• 1 x M.2 2242 SATA SSD
• TPM 2.0 onboard

Ordering Information

DNA 140 (P/N: 10L00014000X0)

Intel Atom^® x7433RE processor, 4 cores, 4 x 2.5GbE RJ45 ports,
1 x 65W 12V DC-in power adapter (support 2 x Quectel RM520N-GL)

DNA 140-T (P/N: 10L00014001X0)

Intel Atom^® x7433RE processor, 4 cores, 4 x 2.5GbE RJ45 ports,
1 x 65W 12V DC-in power adapter (supports 2 x Telit FN990A28)
